| Unità vendibili: | Set/Sets |
|---|---|
| Tipo pacchetto: | Imballaggio in legno |
| Esempio immagine: |
|
Pacchetto: Imballaggio in legno
Trasporti: Ocean,Land
Luogo di origine: Cina
Porta: SHANGHAI,QINGDAO,LIANYUNGANG
Tipo di pagamento: L/C,T/T
Incoterm: FOB,CIF,EXW
Guosheng Intelligent Technology Machine Tool Tool Co., Ltd. è una raccolta di produzione e vendite di macchine utensili, accessori per macchine utensili e accessori, manutenzione e trasformazione della macchina utensile come una delle società integrate. L'azienda ha una propria marca di macchina per tornio CNC, centri di lavorazione, segale, macchina perforatrice, macinazione, macchina per forme in metallo, personalizzazione speciale e altre serie di prodotti per macchine utensili.
【Descrizione del prodotto】
1. La macchina ha una struttura ragionevole, una buona rigidità, un bell'aspetto e un facile funzionamento.
2, la guida guida longitudinale del tavolo adotta la guida di guida a sfere in acciaio, la trasmissione sincrona della cinghia, la luce e flessibile.
【 Parametro tecnico】
|
Technical specification |
Unit |
M618 |
|
|
Maximum stroke of table (length × width) |
mm |
490×180 |
|
|
Maximum distance from table to spindle center |
mm |
335 |
|
|
Table slide |
|
Steel ball V flat rail |
|
|
Maximum capacity of table |
Kg |
200 |
|
|
Table size (length × width) |
mm |
450×150 |
|
|
Table T-slot |
mm×n |
14×1 |
|
|
Hand wheel feed quantity |
mm |
0.02/ grid 4.0/ circle |
|
|
Feed quantity of upper and lower handwheel |
mm |
0.01/ cell 2.0/ circle |
|
|
Grinding wheel size (outer diameter × width × inner diameter) |
mm |
￠180×13×￠31.75 |
|
|
Spindle speed |
50Hz |
rpm |
2850 |
|
Spindle motor |
Kw |
1.1 |
|
|
Cooling pump |
Kw |
0.4 |
|
|
Overall dimensions of the machine (L × W × H) |
mm |
1550×1150×1590 |
|
|
Packing box size (L × W × H) |
mm |
1000×1150×1760 |
|
|
Gross weight, net weight |
T |
O.75、 0.65 |
|
【 Descrizione della configurazione 】
|
disposition |
Brand manufacturer |
remark |
|
Machine tool spindle |
Homemade, the company through 5 processes of processing |
Lathe roughing, then tempering, lathe finishing, high-frequency tempering, cylindrical grinding machine finishing |
|
Lead screw |
self-restrained |
After years of technical transformation of skilled workers, the knife cannot be dropped |
|
motor |
Nantong Guanshun motor |
Jiangsu famous brand |
|
Permanent magnet chuck |
Nantong Xinci |
Jiangsu famous brand |
|
Bed rail and column rail |
All adopt gantry guide grinding and water linear grinding processing, accuracy and durability are improved |
|
|
Machine tool casting |
Nantong, Jiangsu, are standard T250 material |
|
【 Accessori standard】
|
Product name |
quantity |
Product name |
quantity |
|
Surface grinding machine |
1 |
Balance stand |
1 |
|
Toolbox |
1 |
Balance frame mandrel |
1 |
|
Flange wrench |
1 |
Axis of balance |
1 |
|
A Phillips screwdriver |
1 |
Grinding wheel corrector |
1 |
|
Open end wrench 12 x 14 |
1 |
Gold fountain pen |
1 |
|
Open end wrench 17 x 19 |
1 |
Grinding wheel and grinding wheel clamp |
1 |
|
Open end wrench 19 x 22 |
1 |
The drain pipe |
1 |
|
Allen wrench 3 |
1 |
Flush the wire tube |
1 |
|
Allen wrench 4 |
1 |
Floor mat |
3 |
|
Allen wrench 5 |
1 |
Foot screw |
3 |
|
Allen wrench 6 |
1 |
cistern |
1 |
|
Allen wrench 8 |
1 |
Permanent magnet sucker 400*150 |
1 |
